PT32

Specification

Tubes	Braces	Alloy	TUBES	BRACES	ALLOY
50 x 2 mm (1.97 x 0.08 in)	16 x 2 mm (0.63 x 0.08 in)	EN AW-6082 T6	50 x 2 mm (1.97 x 0.08 in)	16 x 2 mm (0.63 x 0.08 in)	EN AW-6082 T6

Ladder, not to be confused with a step ladder! Our PT32 comfortably sits as the most lightweight and space efficient system within the PT range, sitting at only 290mm x 50mm in profile. Installed correctly this system can still achieve 12m spans, making it ideal for most settings from suspended lighting in tight areas to roadshows where space is key. As with all other variants in our PT range, all you need to connect the trusses together is a small hammer and a pair of good hands, because with TrussWarehouse all connection sets are included FREE!

*Please note, the loading tables were calculated while orientated vertically. Horizontal orientation is achievable if installed with supporting wires or bracing, additional structural reports will be required. Contact us for more information.

The PT32 truss line is commonly used as a subbeam for carrying equipment in larger grids that move vertically. It is also well-suited for constructing small to mid-sized structures. A key advantage of the PT32 truss is its stackable design, which enhances efficiency in transport and storage. This truss type is often referred to as ladder truss, bisystem, duo truss, I-Beam, or double truss

Key features and benefits:

290 mm (11.42 in) ladder truss
Certified 50 x 2 mm (1.97 in x 0.08 in) tube
Available in various lengths up to 5 m / 16.40 ft
Certified spans up to 12 m / 39.37 ft
Interior & exterior applications
Connection kit supplied with straights and corners
Compatible with 8001, 8002, 8004, 8007, 8011, 8015, 8016, 8017, 8018, 8020, 8021, 8023, 8031, 8032, 8033, 8034, 8035, 8036, 8037 clamps
Claw clamp 50 for in pipe welding on request
Snap clamp compatible (8102-8105)
Quicklock connection system for quick and easy assembly
Powder coat colour finish available on request

Price on request

PT32 | 290 mm wide ladder truss with quick-lock connection | trussaluminium – for all your aluminium truss needs
